Premium home elevator
Vector Pro
The apex of residential elevation.
5.0 on Google Built to AS 1735 5 Year Parts Warranty
Why choose it
Why homeowners choose the Vector Pro
-
Ultra-compact footprint
Often fits into the space of a standard closet.
-
Whisper-quiet operation
One of the quietest hydraulic lifts in the Australian market, with no loud noise and no oil smell.
-
Italian inspired design
More than a lift, it's a statement of style.
-
Customisable finishes
Complete bespoke sizing and a choice of swing door styles.
Specifications
Vector Pro at a glance
- Rated load 400 kg (5 person)
- Rated speed 0.25 m/s
- Travel 10 m · up to 4 stops
- Headroom 2300 mm (reduced model 2100 mm)
- Pit depth 120 mm
- Drive Hydraulic
- Motor Submerged worm screw hydraulic
- Machine room None · small pump cupboard
- Noise (showroom unit) 42 dB measured
- Current draw Around 14 A (varies by configuration)
- Power Single phase 230VAC
- Cabin sizes 750 × 700 to 1100 × 1350 mm
- Doors Swing doors (manual standard, automatic options)
- Wheelchair friendly Yes
- Installation 1–2 weeks
- Warranty 5 Year Parts Warranty
See full specifications
| Rated load | 400 kg (5 person) |
|---|---|
| Rated speed | 0.25 m/s |
| Max travel | 10 m, up to 4 stops |
| Pit depth | 120 mm |
| Headroom | 2300 mm (reduced headroom model 2100 mm) |
| Drive type | Hydraulic |
| Motor | Submerged worm screw hydraulic motor |
| Machine room | Not required, the pump fits in a small cupboard |
| Noise level | 42 dB (measured on our showroom unit) |
| Current draw | Around 14 A, depending on configuration |
| Door type | Swing doors: Manual Single Swing (standard), Automatic Single Swing, Automatic Centre Swing |
| Cabin type | Closed Cabin / Platform Cabin |
| Power supply | Single Phase 230VAC |
| Standard cabin sizes | 750 x 700 mm to 1100 x 1350 mm |
| Bespoke sizing | Complete Bespoke Sizing Available |
| Wheelchair friendly | Yes |
| Customisation | Yes |
| Installation | 1–2 weeks |
| Warranty | Factory backed 5 Year Parts Warranty |
Comparing drive types? Vector Pro vs Zenith Ultra →Atlus (screw drive) vs Vector Pro (hydraulic) →
Engineered for excellence
What's inside the Vector Pro
-
Leak-proof ram design
Zero leaks, spills or odours, so there is no oil smell. A clean, reliable, maintenance-free hydraulic system.
-
Submerged worm screw hydraulic motor
Engineered for whisper-quiet operation, with no noise or vibration. The pump needs only a small cupboard, with no machine room.
-
Smart cabin touch panels
Crystal-clear displays and effortless, intuitive control.
-
Advanced rollers
Minimise friction and absorb bumps for an exceptionally smooth, stable ride.
-
Safety braking system
Robust, reliable braking with instant, secure stopping power.
Real projects, real reviews
Installed and serviced by Lift Ease
-
“Lift Ease installed a home elevator for my parents and the whole experience was fantastic. The communication from start to finish was outstanding. The lift itself is quiet, smooth and has been life changing for mums mobility. Professional punctual and no surprise costs. Highly recommended for anyone considering a residential elevator.”
Michael Melling · Google review
-
“Thank you to the boys and Jared! Great workers, great communication and flawless precision!”
Evan Clappaert · Google review
FAQs
Vector Pro questions
How much space does the Vector Pro need?
The Vector Pro is designed to be compact, often fitting into the space of a standard closet. We offer a free consultation to assess your home's specific needs.
What pit does the Vector Pro need?
The Vector Pro needs a pit of just 120 mm.
How far can the Vector Pro travel?
The Vector Pro travels up to 10 m and serves up to 4 stops, with cabins up to 1100 × 1350 mm.
Does the Vector Pro need a machine room?
No. Thanks to its submerged worm screw hydraulic motor, the pump needs only a small cupboard, with no machine room.
Is the Vector Pro noisy, or does it smell of oil?
No. The Vector Pro is one of the quietest hydraulic lifts in the Australian market, with no loud noise: our showroom unit measured 42 dB. Its leak-proof ram design means zero leaks, spills or odours, so there is no oil smell.
What power does the Vector Pro need?
Single phase 230VAC, like all our home elevators. It draws around 14 A depending on configuration, less than the standard 32 A typical of electric traction. Only the E1 commercial lift needs three phase power.
Is the Vector Pro wheelchair friendly?
Yes. Standard cabins range from 750 × 700 mm to 1100 × 1350 mm, with complete bespoke sizing available. Raise wheelchair access at the first site visit so the cabin is specified for it from the start.
What happens if the power goes out?
Home lifts have a battery backup that brings the car to the nearest landing and opens the door, so nobody is left sitting in a stopped lift.
What maintenance is required?
We recommend a minimum of one service per year, twice-yearly for heavily used lifts, or as outlined by the manufacturer's servicing schedule.
How long does installation take?
Installation of the Vector Pro typically takes 1–2 weeks.
Experience the future today
Ready to elevate your home with the Vector Pro? Contact our specialists to learn more about its features and get a personalised quote for your project.
